Niaux 200

Concave Disc Blade Raised Center Ø519×6
ref. D20-0021

Product description

This disc features a cylindrical central hub designed to directly accommodate a bearing. Its one-piece design simplifies assembly, enhances durability, and reduces the risk of deformation under stress. Thanks to better distribution of rotational forces, it also ensures more uniform wear and increased operational stability. It is an economical, long-lasting, and low-maintenance solution, perfectly suited for demanding conditions.

• Simplified assembly with integrated bearing seat
• One-piece, durable design
• Fewer components, less maintenance
• Enhanced strength and even wear distribution

Mecapart ref.	D20-0021
Brand	Niaux 200
Product category	Tillage Disc Blades
Product family	Concave Disc Blades Raised Center
Weight	8.785
Thickness	6.0
Diameter	519
Profile	Concave
Hub design	Raised Center
Radius	R670
Depth (mm)	52.00
Dimension 1 (mm)	162.00
Edge	Notch
Notch	Elliptical
No. of notches	10
Bevel	Outer
Center Hole	Round hole 60.5mm
Peripherical Holes	4 round hole 14mm
PCD (mm)	113.00
OEM name	GREAT PLAINS
OEM reference	820-460C
