Niaux 200

V-Cut Disc Blade Ø563×5
ref. D22-0010

Product description

Featuring a conical profile and V-shaped notches, the V-Cut Disc is designed to excel in dry or very hard soils. Its design promotes deep soil penetration while ensuring excellent residue mixing. Its slower rotation speed allows for more controlled and efficient penetration, particularly in conventional tillage practices. As a result, it offers a strong balance between aggressiveness and efficiency.

• Conical shape for deeper soil engagement
• Excellent residue flow and clearance
• Ideal for hard, dry soils
• Reduces blockage and improves efficiency

Mecapart ref.	D22-0010
Brand	Niaux 200
Product category	Tillage Disc Blades
Product family	V-Cut Disc Blades
Weight	9.752
Thickness	5.0
Diameter	563
Profile	Conical
Hub design	Concave center
Depth (mm)	59.00
Dimension 1 (mm)	290.00
Edge	Notch
Notch	Triangular
No. of notches	16
Bevel	Inner
Center Hole	Round hole 25mm
Peripherical Holes	4 square bolt holes 13.5mm
PCD (mm)	158.75
