Niaux 200
Concave Disc Blade Flat Center Ø576×5
ref. D23-0001
Product description
With a flat center, this concave disc is designed for stable mounting and balanced force distribution. It offers a good compromise between penetration and precision, making it a smart choice for consistent surface work without mechanical overload.
- Excellent mounting stability
- Balanced force distribution during work
- Smooth, consistent field performance
- Accurate depth control
| Mecapart ref. | D23-0001 |
| Brand | Niaux 200 |
| Product category | Tillage Disc Blades |
| Product family | Concave Disc Blades Flat Center |
| Weight | 9.233 |
| Thickness | 5.0 |
| Diameter | 576 |
| Profile | Concave |
| Hub design | Flat center |
| Radius | R840 |
| Depth (mm) | 46.00 |
| Dimension 1 (mm) | 170.00 |
| Edge | Notch |
| Notch | Elliptical |
| No. of notches | 10 |
| Bevel | Outer |
| Peripherical Holes | 4 round bolt holes 13mm |
| PCD (mm) | 110.00 |
| OEM name | PÖTTINGER |
| OEM reference | 9771.03.025.1 |
